Geekworm X1301 HDMI to CSI-2 Shield for Raspberry Pi 5/4B/3B+/3B Support 1080P@60fps
Brand: Geekworm
About this item
The Geekworm X1301 HDMI to CSI-2 Shield is a specialized video interface board designed to bring HDMI input capabilities to compatible Raspberry Pi platforms. It uses the Toshiba TC358743XBG bridge chip to convert incoming HDMI signals into MIPI CSI-2, allowing the Raspberry Pi to receive and process HDMI video similarly to a camera input. The module supports resolutions up to 1920 × 1080 at 60fps, making it suitable for smooth Full HD video applications.
A key advantage of the X1301 is its HDMI pass-through capability, which allows the original HDMI signal to be displayed on an external TV, monitor, or projector while the Raspberry Pi processes the input. It also supports HDMI audio transmission through I²S, making it useful for applications requiring synchronized audio and video.
The board features a 22-pin, 0.5 mm pitch CSI-2 connector and four-lane MIPI CSI-2 connectivity. Its applications include video capture, smart displays, KVM-over-IP systems, digital media adapters, set-top boxes, entertainment systems, and embedded video projects.
Specifications
| Category | Multi-brand Raspberry Pi Add On Boards (hats) |
|---|---|
| Compatibility: | Raspberry Pi 5, 4B, 3B+, 3B |
| Connector Type: | CSI-2 22-pin FPC |
| Audio input/output Port | HDMI audio via I²S |
| Shipping Weight | 0.07 kg |
| Shipping Dimensions | 9 × 13 × 4 cm |
