About this item

The 10A Motor Driver Shield – MD10 is an Arduino-compatible shield designed for controlling high-current brushed DC motors. It supports motor voltage ranges from 7V to 30V and can handle up to 10A of continuous current, with a peak of 15A for up to 10 seconds. The shield utilizes solid-state components, eliminating mechanical relays and ensuring faster response times. Its fully NMOS H-Bridge design offers better efficiency without the need for a heat sink. The shield features stackable I/O header pins, selectable digital pins for PWM (speed) and DIR (direction), and a PWM frequency of up to 10kHz

Specifications

Motor Control	Bi-directional control of 1 brushed DC motor
Voltage Range	Supports 7V to 25V motor voltage
Current Capacity	Maximum 10A continuous, 15A peak (10 seconds)
Components	Solid state components for faster response and no mechanical wear
H-Bridge	Fully NMOS design for better efficiency, no heat sink needed
